ACOM 1000

The ACOM 1000 is a complete and self-contained linear amplifier that covers all amateur bands from 1.8 through 54 MHz and provides over 1000 W output power with less than 60 W exciter drive. The TRI (True Resistance Indicator) is a powerful tuning aid which, together with the automatically controlled input attenuator, helps the operator to quickly and precisely match antennas (5-10 seconds typically).

No antenna tuner required for antenna SWR up to 3:1 (and higher on some bands). The amplifier will perform the functions of an antenna tuner, thus enabling operators to change antennas faster and use them over a wider frequency range (saving tuning time).

ICOM IC-9700

The Icom IC-9700 is the first VHF/UHF/1200 MHz transceiver which introduces the RF direct sampling system for the 144 and 430 MHz bands, a real-time spectrum scope and waterfall function. The radio including a built-in 1200 MHz band, 4.3 inch TFT colour touchscreen display, full duplex with Dualwatch on separate bands, Satellite mode, D-STAR DV (Digital Voice) /DD (Digital Data) modes and Terminal/Access point modes. Also, a newly designed power amplifier and cooling system provide stable and high-efficiency operation, even when continuously transmitting for a long time.

Without installing any option units the IC-9700 includes D-STAR (a digital voice and data protocol specification for amateur radio) DV and DD modes. In addition, Satellite mode is built-in! There are three antenna connectors for 144, 430, and 1200 MHz.

Here's a few of the features of the new IC-9700

• All mode, tri-band transceiver covering 144 MHz, 430 MHz as well as 1.2GHz
• Supports CW/AM/SSB/FM/RTTY and D-STAR Digital Voice and Digital Data modes
• 144MHz and 430MHz band is direct sampling. The 1.2GHz uses down conversions as well
• Full duplex operation/ Dual Watch (no VHF/VHF or UHF/UHF capability)
• PA will provide a powerful 100 W (144 MHz), 75 W (430 MHz) and 10 W (1200 MHz) output
• 4.3" touchscreen colour TFT LCD
• Smooth satellite operation with normal/reverse tracking and 99 satellite channels
• D-STAR provides clear digital audio
• Voice recording/playback function (SD memory card)
• Audio scope
• CW full break-in

My primary VHF and UHF transceiver and primary D-Star unit

(144MHz - 146MHz, 432MHZ - 440MHz, 1240MHz - 1325MHz)

Wavenode WN-2

The Wavenode WN-2 power meter measures and displays output power and SWR of up to four radios/antennas at the same time. Sensors are available for 1.6 to 1300 MHz and up to max. 8KW. The measured data is displayed on the main Wavenode WN-2 unit and can be displayed on a computer connected via USB using the software for Windows. The Wavenode WN-2 key functions are:

• Monitor 4 sensors simultaneously for peak, Average power and coax SWR.
• Direct USB full speed interface.
• Backlit LCD display for stand-alone operation- PC is optional.
• Oscilloscope and Spectrum Analysis of the RF Modulation- Observe IM and “Splatter” frequency components in in real-time.
• Wide range of sensors cover 100 milliwatt to 8KW, 1.6 Mhz to 1.3 Ghz.
• 16-bit RISC processor, 12 bit A/D converter and rugged construction.

YAESU FT891

The FT-891 offers 100 watts of HF/50MHz output power with efficient dual internal fans. Coupled with Yaesu's legendary receiver design, triple conversion with a 1st IF frequency of 69.450MHz for outstanding performance.

Equipped with a 3KHz roofing filter as standards the FT-891 real DSP provides effective and optimal QRM rejection.

My primary mobile HF transceiver

(1.8MHz - 30MHz)

YAESU FT817ND

The FT-817ND was the world’s first HF/VHF/UHF self-contained battery-powered Multi-mode Portable Transceiver. With a 1400 mAh NiMH rechargeable battery pack the FT-817ND is a favourite with those taking to the hills or working portable.

Despite its incredibly small size (5.3" x 1.5" x 6.5"), the FT-817 delivers big performance! Its next-generation PA puts out five watts on all HF bands, plus the 50 MHz, 144 MHz, and 430 MHz bands, on all popular operating modes: USB/LSB/CW/AM/FM/Packet/PSK-31/RTTY.

The FT-817ND has extended frequency coverage, which includes reception on 100 kHz - 56 MHz, 76 - 108 MHz (W-FM only), 108 - 154 MHz, and 420 - 470 MHz.

My primary portable HF transceiver and secondary mobile

(1.8MHz - 30MHz)

My primary input of 433MHz into a 2.4GHz upconverter for QO-100 satellite

ICOM IC-2820

The IC-2820H receives 118-549.995 and 810-999.990MHz with dualwatch receiver capability that allows you to receive two bands simultaneously (including within a single band). Almost all VHF& UHF communications are available to you!

A MOSFET power amplifier provides a powerful 50W on both the 2m and 70cm bands, making this compact rig's signal travel for miles! Output power is selectable in 3 steps.

My primary VHF and UHF mobile transceiver and primary mobile D-Star unit

(144MHz - 146MHz, 432MHz - 440MHz)

HYTERA MD785

The MD785 is strictly compliant with MIL-STD-810 C/D/E/F and IP54 standards, ensuring outstanding performance even under harsh environments.

With the combined application of narrowband codec and digital error-correction technologies, MD785 is capable of ensuring you superior voice under noisy environments or at the edge of the coverage area.

Besides the intrinsic encryption of the digital technology, MD785 provides enhanced encryption capability (such as 256-bit encryption algorithm) and the Scrambler feature (selectable).

My secondary UHF mobile transceiver and primary DMR unit

(432MHz - 440MHz)

YAESU FTM-100DR

The FTM-100DR's single receiver design provides 50 solid Watts of RF power on both the 144 and 430 MHz amateur radio bands, while still being host to a feature packed suite of both C4FM Digital and FM Analog communications. The FTM-100DR operates in three (3) Digital modes and an (1) Analog mode. This feature packed radio is Yaesu's first Digital Mobile equipped with their new Automatic Mode Select (AMS) function that instantly detects the received signal mode.

My secondary VHF and UHF mobile transceiver and primary VHF/UHF C4FM (System Fusion) unit

(144MHz - 146MHz, 432MHz - 440MHz)

Satellite Equipment

For details of my satellite station and equipment click on the link to my dedicated satellite page.
